TC-80/120 Taylor-Dunn
Chassis: Battery: |
Type: One 12 volt (lead acid) System Voltage: 12 Charger: N/A |
Chassis: Brakes: |
Rear: Drum Front: Hydroboost Hydraulic Caliper Disc Parking: Hand Operated Independent Parking Brake |
Chassis: Frame Construction: |
Unibody steel frame construction with heavy duty front & rear plates |
Chassis: Powertrain: |
Type: Combustion Power: N/A Transmission: Automatic 3-speed, Neutral Start Interlock Switch Drive: Controller: N/A |
Chassis: Steering: |
Hydrostatic with Dual Action Steer Cylinder |
Chassis: Suspension: |
Rear: Rigid mounted Front: Leaf springs |
Chassis: Tires: |
Rear: 7.50 x 16 dual Front: 7.50 x 16 |
Dimensions: Deck: |
Width: N/A Length: N/A Height: N/A |
Dimensions: Height: |
Less Cab: 66″ (167 cm) With Cab: 92″ (233 cm) |
Dimensions: Hitch Height: |
14″ (35.5cm) |
Dimensions: Length: |
120″ (304 cm) |
Dimensions: Outside Turning Radius: |
170″ (431.8cm) |
Dimensions: Weight: |
12,900 lbs (6,851 kg) – 16,000 lbs (7,267 kg) |
Dimensions: Wheel Base: |
63″ (160.0cm) |
Dimensions: Width: |
65.5″ (166 cm) |
Interior: Instrumentation: |
Coolant temperature, oil pressure, fuel level, volt meter, hour meter, ignition switch, headlight sitch, electric horn |
Interior: Seats: |
Driver: Vinyl Bucket Type, Adjustable Passenger: N/A |
Performance: Load Capacity: |
N/A |
Performance: Passengers: |
1 |
Performance: Range: |
75 Miles (120 km) |
Performance: Speed: |
13 mph (20.8 km/h) |
Performance: Tow Capacity: |
DBP: 8,000 lbs. – 12,000 lbs. Tow Capacity: 120,000 lbs. (54,431 kg) |
Details
The TC-80/120 is available with multiple engine packages to meet various environmental conditions. The unit is equipped with fully welded steel frame construction for durability and reliability. The unit has excellent steering capability and maneuverability.
