BT-280 48V GT Taylor-Dunn
Chassis: Battery: |
Type: Eight 250 amp hr., 6 volt (lead acid) System Voltage: 48 Charger: Built-In |
Chassis: Brakes: |
Rear: Hydraulic discs Front: Hydraulic disc Parking: Hand |
Chassis: Frame Construction: |
Steel unitized body with heavy duty 16 gauge smooth plate |
Chassis: Powertrain: |
Type: Electric Power: 110/220V, 50/60Hz Transmission: Transaxle Assembly, Sealed Helical Gear Primary Reduction to Hypoid Ring and Pinion Gears Drive: Controller: SEM |
Chassis: Steering: |
Manual, Re-circulating Ball |
Chassis: Suspension: |
Rear: Leaf springs w/dual rear shocks Front: Leaf springs |
Chassis: Tires: |
Rear: 5.70 x 8 pneumatic Front: 5.70 x 8 Load Range C, Pneumatic |
Dimensions: Deck: |
Width: N/A Length: N/A Height: N/A |
Dimensions: Height: |
Less Cab: 44″ (112 cm) With Cab: N/A |
Dimensions: Hitch Height: |
12.5″ (31.8cm) |
Dimensions: Length: |
136.7″ (348 cm) |
Dimensions: Outside Turning Radius: |
160″ (411cm) |
Dimensions: Weight: |
1,586 lbs. (719 kg.) |
Dimensions: Wheel Base: |
78″ (198cm) |
Dimensions: Width: |
50″ (127 cm) |
Interior: Instrumentation: |
Smart View Display (Battery status indicator, hour meter, system status monitor, speedometer), reverse buzzer, forward/reverse selector, key switch, electric horn |
Interior: Seats: |
Driver: Passenger: |
Performance: Load Capacity: |
3,000 lbs. (1,360 kg.) |
Performance: Passengers: |
8 |
Performance: Range: |
24 miles (38 km) |
Performance: Speed: |
11 mph (17.7 km/h) |
Performance: Tow Capacity: |
12,500 lbs. (5,682 kg) |
Details
Equipped with a 48 volt GT drive train, BT-280 48V GT can travel at speeds of 10.5 mph, while providing a range of 24 miles in a single charge.
Low step height and increased visibility while traveling at low speeds in congested areas make BT-280 an ideal solution for your personnel moving applications. Low noise and zero pollution accompanied with low operating and maintenance cost makes BT-280 the most cost effective solution when compared to its gasoline alternatives.
BT-280, equipped with a roll out battery box, can provide extended range for your application. Ideal for use in public venues, BT-280 is one of the safest and most economical ways to transport your customers or employees.
